Description
| Manufacturer | Compleo |
| Product name | eBOX professional |
| Charging mode | AC, mode 3 |
| Number of charging points | 1 |
| Charging connector | Type 2 socket, optional Type 2 charging cable (6.5 m) |
| Maximum charging power | 22 kW |
| Output voltage | – |
| Maximum output current | 32 A |
| Input voltage | 230 – 400 V |
| Phases | 3 |
| Max input current | 32 A per phase, configurable |
| Efficiency | – |
| Standby consumption | 6 W |
| IP protection class | IP55 |
| Impact resistance | IK10 |
| Dimensions (H x W x D) | Wall mounted: 450 x 180 x 170 mm (incl. eCLICK) |
| Weight | 3.1 – 7.4 kg (depending on options) |
| Mounting | Wall mounted (wm); optional: Base mounted (bm) |
| Communication protocols | OCPP 1.6 JSON, Modbus TCP/IP |
| Display | Without |
| Noise level | – |
| Environmental operating temp | -30°C to +50°C |
| Certification | CE, UKCA, RoHS, REACH, GPSD, WEEE |
| User interface | LED displays for authorisation and vehicle status |
| Authorization methods | Free charging, RFID, Smartphone app |
